HYUNDAI IONIQ 5 VARIANT BUILD UP
Dimensions
Specification Value
Length 4,655 mm
Width 1,890 mm
Height 1,625 mm
Wheelbase 3,000 mm
Seating Capacity 5
Body Type Electric SUV
These are the official Hyundai India dimensions for the 2026 IONIQ 5.
________________________________________
Motor (Engine) Specifications
Specification Value
Motor Type Permanent Magnet Synchronous Motor (PMSM)
Drive Type Rear-Wheel Drive (RWD)
Maximum Power 168 kW (228.5 PS)
Maximum Torque 350 Nm
Transmission Single-Speed Reduction Gear
Battery Capacity 84 kWh
Battery Type Liquid-Cooled Lithium-Ion
ARAI Range Up to 690 km
The Indian-spec IONIQ 5 is offered in a single 84 kWh RWD configuration.
________________________________________
Charging Specifications
Specification Value
Platform E-GMP (800V Architecture)
AC Charging 11 kW
AC Charging Time (10–100%) 7 hr 35 min
DC Fast Charging (10–80%) 18 min
Maximum DC Charging Capability Up to 350 kW
Vehicle-to-Load (V2L) Yes
________________________________________
Tyre & Wheel Size
Specification Value
Tyre Size 255/45 R20
Wheel Size 20-inch Aero Alloy Wheels
Spare Wheel Tyre Mobility Kit (TMK)
Official Hyundai India specification.
________________________________________
Official Hyundai India Colours
The 2026 Hyundai IONIQ 5 is available in:
• Gravity Gold Matte
• Midnight Black Pearl
• Titan Grey
• Optic White
Official Hyundai colour palette for India.
________________________________________
Suspension & Brakes
Specification Value
Front Suspension MacPherson Strut
Rear Suspension Multi-Link
Front Brakes Disc
Rear Brakes Disc
Hyundai IONIQ 5 (84 kWh)
Safety
• 6 Airbags
• Electronic Stability Control (ESC)
• ABS with EBD
• Vehicle Stability Management (VSM)
• Hill Start Assist
• All-Wheel Disc Brakes
• TPMS
• Electronic Parking Brake
• Surround View Monitor (360° Camera)
• Blind View Monitor
• Front & Rear Parking Sensors
• Parking Collision Avoidance Assist – Rear
• Side Parking Distance Warning
• Driver Attention Warning
• Safe Exit Assist
• ISOFIX Child Seat Anchors
Hyundai SmartSense (ADAS)
• Forward Collision Avoidance Assist
• Lane Keeping Assist
• Lane Following Assist
• Blind Spot Collision Avoidance Assist
• Rear Cross Traffic Collision Avoidance Assist
• Smart Cruise Control with Stop & Go
• High Beam Assist
• Driver Attention Warning
________________________________________
Exterior
• Parametric Pixel LED Headlamps
• Parametric Pixel LED DRLs
• Parametric Pixel LED Tail Lamps
• Flush Door Handles
• Powered Tailgate
• Solar Control Glass
• Vehicle-to-Load (V2L)
• Active Air Flaps
• Rear Spoiler
• Aero-Optimized Design
• 20-inch Aero Alloy Wheels
________________________________________
Interior
• Sustainable Eco-Processed Materials
• Leather Upholstery
• Ventilated Front Seats
• Heated Front Seats
• Power Adjustable Front Seats
• Sliding Centre Console
• Sliding Rear Seats
• Dual-Zone Automatic Climate Control
• Rear AC Vents
• Ambient Lighting
• Panoramic Vision Cabin
________________________________________
Infotainment & Connectivity
• Dual 12.3-inch Screens
o Digital Instrument Cluster
o Infotainment Display
• Connected Car Navigation Cockpit (ccNC)
• Bluelink Connected Car Technology
• Wireless Android Auto
• Wireless Apple CarPlay
• OTA (Over-the-Air) Updates
• Voice Recognition
• Bose Premium Audio System
• Wireless Phone Charger
• Digital Key Functions
• In-Car EV Charging Payments
